MS Series - Life Sciences Temperature Probes Type NTC Thermistors

MS Series 0.078" dia. These thermistors offer a precision method of life science and patient care temperature sensing. Our disposable sensors meet the necessity of low cost without compromising high quality and precise accuracy.

Features

項目符號 Interchangeable tolerance
項目符號 Custom designs
項目符號 Skin and catheter disposable sensor designs
項目符號 Opera table with YS1 400 and 700 temperature monitor instruments
項目符號 Top Quality
項目符號 High Stability
項目符號 Fast response
項目符號 Low Cost and Long Life

Specifications

項目符號 Operating temperature range: MS Series thermistors may be intermittently cycled at temperatures from -50℃ to 150℃. Optimum stability is achieved when thermistors are operated at temperatures within the specified temperature range.
項目符號 Tolerance: +0.10℃, +0.20℃, +0.50℃ or +1.00℃
項目符號 Dissipation constant: 2.5mW/oC in still air and 13mW/oC in stirred oil.
項目符號 Thermal time constant: Typically 1.25 seconds in still oil.
項目符號 Custom options: Various lead materials, termination and lengths.

Options

項目符號

Resistance at 25oC

10K: 10K ohms

100K: 100K ohms

30K: 30K ohms

　
項目符號 Tolerance @25oC
01: +0.10℃ 02: +0.20℃
05: +0.50℃ 10: +1.00℃
項目符號

B value 25oC / 85oC

3892K

3977K

　

Products of MS Series

Part No. Resistance at 25oC Lead Material Lead Length Tolerance B Value (25oC / 85oC)
MS10K-28123-023977 10K ohms 28 AWG 12.30" +0.2℃ 3977
MS100K-28123-023977 100K ohms 28 AWG 12.30" +0.2℃ 3977

　
