Plastic – coated Types (9P Types)



Maximum Ratings

Characteristics E (at 25)



Applied

Allowable

Ambient

Cell Resistance A



Response Time at 10 lx D



Voltage

Power

Temperature

10 lx (at 2856K)

0 lx B

C





Type No.

at 25

Dissipation

Ta

Min.

Max.

Min.

100~10 lx

Rise Time

Decay Time





at 25



(K

(K

(M

Type

Type

Type



(Vdc)

(mW)

()

ohm)

ohm)

ohm)



(ms)

(ms)

9001

150

90

-30~+75

4

11

0.3

0.65

60

25

9002

150

90

-30~+75

9

20

0.5

0.6

60

25

9002-1

150

90

-30~+75

11

27

0.5

0.7

60

25

9003

150

90

-30~+75

16

33

1

0.8

60

25

9003-1

150

90

-30~+75

23

33

1

0.85

60

25

9004

150

90

-30~+75

27

60

2

0.85

60

25

9005

150

90

-30~+75

50

94

2.5

0.9

60

25

9005-1

150

90

-30~+75

48

140

20

0.9

60

25

9006

150

90

-30~+75

80

200

5

1

60

25

9007

150

90

-30~+75

10

100

1

0.8

60

25

9008

150

90

-30~+75

10

200

20

0.85

60

25

9103

150

90

-30~+75

20

45

1

0.8

60

25

9200

150

90

-30~+75

10

50

5

0.9

70

15

9203

150

90

-30~+75

5

20

20

0.9

70

15




A. Measured with the light source of a tungsten lamp operated at a color temperature of 2856K.

B. Measured 10 seconds after removal of incident illuminant of 10 lux.

C. Gamma characteristic between 10 lux and 100 lux and given by



Where R100, R10: cell resistances at 100 lux and 10 lux respectively

E100, E10: illuminant of 100 lux and 10 lux respectively

D. The rise time is the time required for the cell conductance to rise to 63% of the saturated level. The decay time is the time required for the cell conductance to decay from the saturated level to 37%.

E. All character is tics are measured with the light history conditions: the CdS cell is exposed to light (100 to 500 lux) for one to two hours.
